COMPACTION

We have an extensive range of compaction equipment including plate compactors, tampers, smooth drum rollers and padfoot rollers. Get in touch with our experts and talk about your requirements today.

50kg Plate Compactor

Ideal for smaller compaction jobs, sloping sites, landscape paving, Soil, screed, narrow trench work and general light compaction work.

  • Smaller compaction jobs
  • Narrow trench work
  • Sand
  • Soil,
  • Pavers
  • Screed
  • Path
  • Driveways
  • Manoeuvrable
  • Simple to operate
  • Folding handle for easy transportation
  • Shock absorbing mounts to reduce vibration through the handle
  • Plate size: 420 x 295
  • Weight 50kg
  • Centrifugal Force: 7.2kn
  • Frequency: 6200vpm
  • Travel speed max: 25m/min
  • Heavy duty cast steel base ribbed for extra strength
  • Oil bathed vibration head mounted on the front for easy access
  • Lifting mounts with folding handle
  • Lifting frame incorporating a front lifting handle
  • Reliable Honda GX100 3.0hp 4 stroke engine
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • Station wagon required
50kg Plate Brochure50kg Plate ManualCall 0800 652 555

Delivery Service Available

65kg Plate Compactors

Ideal for light to medium work, general construction and contracting jobs to compact sand, soil, gravel and bedding in paving and bricks. Easy to control and very manoeuvrable.

  • Narrow trench work
  • Sand
  • Soil,
  • Pavers
  • Screed
  • Path
  • Driveways
  • Manoeuvrable
  • Simple to operate
  • Folding handle for easy transportation
  • Shock absorbing mounts to reduce vibration through the handle
  • Plate size 540mm x 350mm
  • Weight: 65kg
  • Centifugal Force: 10.1kn
  • Frequency: 6200vpm
  • Travel speed max: 25m/min
  • Reliable HondaGX120 4.0hp OHC 4 stroke engine
  • Heavy duty plate steel base with double skin on the rear section
  • Oil bathed vibration head mounted on the front for easy access
  • Lifting mounts with folding handle
  • Fully enclosed belt guard to eliminate belt wear and breakage from stones and foreign objects
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • Station wagon required
65kg Plate Brochure65kg Plate ManualCall 0800 652 555

Delivery Service Available

85kg Plate Compactor

Ideal for larger jobs for the general contractor and civil engineering work. Fitted with the new vibration absorbing handle.

  • Trench work
  • Sand
  • Soil,
  • Pavers
  • Screed
  • Path
  • Driveways
  • Manoeuvrable
  • Simple to operate
  • Fold away wheels for easy 1 man shifts
  • Folding handle for easy transportation
  • Shock absorbing mounts to reduce vibration through the handle
  • Plate size: 570mm x 450mm
  • Weight: 90kg
  • Centrifugal Force: 13.7kn
  • Frequency: 5600vpm
  • Travel speed max: 25m/min
  • Unique ‘VAS’ Vibration absorbing handle to eliminate hand/arm vibration
  • Honda GX160 5.0hp OHC 4 stroke engine
  • Optional water tank which slides over the lifting frame
  • Fold-down wheel kit for easy transportation
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • Ute or similar required
85kg Plate Brochure85kg Plate ManualCall 0800 652 555

Delivery Service Available

400kg Reversible Compactor

Ideal for civil engineering, construction and drainage projects with a wide base plate designed for fast compaction of soil, sand and stone material on large surfaces, building foundations and backfill against supporting walls. High compaction capacity, travel speed and feature a full hydraulic reversing mechanism.

  • Trenches / Foundations
  • Retaining
  • Sand
  • Soil
  • Pavers
  • Screed
  • Path
  • Driveways
  • Reversible for ease of use
  • Self-propelling
  • Fast compaction rate
  • Shock absorbing mounts to reduce vibration through the handle
  • Plate size 900mm x 500mm (650 with extension plates)
  • Weight: 423kg
  • Centrifugal force: 55kn
  • Frequency: 4400vpm
  • Travel speed max: 25m/min
  • Full variable speed control
  • On the spot compaction
  • Hydraulic tank included in the handle eliminates air in the oil
  • Multiply anti-vibration points on handle helps eliminate operator fatigue
  • Fold-up handles for transportation and storage
  • Roll bar protecting frame incorporating a lifting point
  • Fully enclosed belt guard
  • Hatz 1B50 diesel engine
  • Electric start and recoil start
  • Hour meter & tachometer standard
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • Ute or Trailer required
400kg Rev Plate BrochureCall 0800 652 555

Delivery Service Available

75kg Tamper

Strong yet light, our Mikasa Tampers are great for construction and civil applications with confined areas, trench work, footings and excavations.

  • Trenches / Foundations
  • Retaining
  • Sand
  • Soil
  • Asphalt
  • Path
  • Driveways
  • Excellent compaction performance
  • Easy loading and transportation
  • Economical to run
  • Manoeuvrable
  • Easy use
  • Great for tight spaces
  • Foot size: 340mm x 285mm
  • Weight: 75kg
  • Impact Force: 14.9kn
  • Blows per minute: 695
  • Jumping Stroke: 50-80mm
  • Honda GX100 3.0hp OHC 4 stroke engine
  • Recoil start
  • Throttle level that controls idle stopping and fuel shut-off
  • Hour meter and tachometer
  • Lifting point on handle
  • Transport roller fitted to main handle for ease of loading
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • Ute required
75kg Tamper Brochure75kg Tamper ManualCall 0800 652 555

Delivery Service Available

1.6T Roller – Smooth Double Drum

Our smooth drum 1.6T rollers offer full-flush compaction on the right and on the left, double traction and double vibration at front and rear. No wheel supports to obstruct compaction work up against curbstones and walls. This unit also has a pressurised water sprinkler system.

  • Roading
  • Asphalt
  • Sand
  • Soil
  • Gravel
  • Driveways
  • Flush finish on asphalt/curbing
  • Double traction
  • Dual vibration
  • Comfortable driver position
  • Easy to use controls
  • Articulated steering increases manoeuvrability
  • Pressurised water sprinkler system
  • Weight:  1.52T
  • Transport length: 2.017 m
  • Transport width: 0.947 m
  • Transport height: 1.8 m
  • Steering:  SL
  • Travel speed: 8 km/h
  • Frequency: 58/66 Hz
  • Roller width: 0.95 m
  • Rollers Ø: 0.575 m
  • Turning radius outside: 2.125 m
  • Statical line load:  8.4 kg/cm
  • Centrifugal force: 23 kN
  • Engine type:  Yanmar 3TNV76
  • Engine power: 15 kW
  • Displacement: 1.115L
  • Revolutions at max torque: 2500 rpm
  • Water tank: 110L
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • NJC Specialty Trailer with the right towing vehicle
  • NJC Transporter
  • Truck with tilt
1.6T Roller BrochureCall 0800 652 555

Delivery Service Available

4T Roller – Smooth Double Drum

Ammann ARX40 vibrating rollers are designed in the fields of roading, construction and landscaping. ARX rollers are very efficient and effective machines for blacktop compaction and for compacting unbonded base layers. With dual vibrating and driving drums this unit has excellent compaction capacity on surfaces including soil, gravel and other varying subgrades. This unit has a travel speed of up tp 10km/h maximum in both forward and reverse as well as a pressurised sprinkler system.

  • Roading
  • Asphalt
  • Subgrade layers
  • Sand
  • Soil
  • Driveways
  • Flush finish on asphalt/curbing
  • Double traction
  • Dual drum vibration
  • Comfortable driver position
  • Easy to use controls
  • Capacity to follow small asphalt paver
  • Articulated steering increases manoeuvrability
  • Pressurised water sprinkler system
  • Weight:  4.125T
  • Transport length:  2.8m
  • Transport width :  1.341m
  • Transport height:  2.332m
  • Steering:  VL
  • Travel speed:  10km/h
  • Frequency:  45/57Hz
  • Roller width:  1.34m
  • Rollers Ø:  0.85m
  • Turning radius outside: 2.581m
  • Statical line load: 15.8kg/cm
  • Centrifugal force: 52kN
  • Engine type: Yanmar 4TNV88
  • Engine power: 30kW
  • Displacement: 2.189L
  • Revolutions at max torque: 2400rpm
  • Water tank: 350L
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • NJC Transporter
  • Truck with tilt
4T Roller BrochureCall 0800 652 555

Delivery Service Available

6T Padfoot Roller

Padfoot rollers are perfect for compacting fine grained soils such as heavy or silty clays in embankments, subgrade layers in pavements and rail road construction and roading projects. Pad foot rollers are designed for drying, crushing and kneading materials to eliminate water and air void. 3-point articulation for outstanding traction and off-road mobility. Simple, intuitive with high climbing ability and a compact dimension.



  • Gravel
  • Soil
  • Subgrade materials
  • Eliminate water and air void in material
  • Pad foot drums ideal for drying, crushing and kneading surface materials
  • Excellent operator visibility from cockpit
  • 3-point articulation for outstanding traction and off-road mobility
  • Simple, intuitive and language-neutral operation
  • Excellent view of the machine and the construction site
  • High climbing ability
  • Compact dimensions
  • Dimensions: L4040mm x W 1500mm x H 2867mm
  • Drum: W 1370mm
  • Height of the padfeet: 80mm
  • Weight:  5.5T
  • Ground clearance: 270mm (centre)
  • Turning radius: 3375mm (inside)
  • Angle of driving slope: ° 43 front /36 rear
  • Vibration frequency: 30Hz
  • Amplitude: 1.45mm
  • Centrifugal force: 69kN
  • Speed:
    • working gear: 0-6km/h
    • Transportation gear: 0-12.05km/h
    • Climbing ability: vibration 55% on / 60% off
  • Engine: KUBOTA V3307-CR-T
  • Power rating: 55.4kW / 74.2HP / 2200rpm
  • Emission standard: EU Stage V / EPA Tier 4
  • Exhaust gas after-treatment: DOC-DPF
  • Noise: 104dB
  • Suitable eye protection
  • Hearing protection
  • Suitable protective mask
  • Protective gloves
  • Suitable footwear
  • NJC transporter
  • Truck with tilt
5T Padfoot Roller BrochureCall 0800 652 555

Delivery Service Available
